Description
TIGER 372 CNC LR 4.0 RC
TIGER 372 CNC LR 4.0 RC, electropneumatic automatic circular sawing machine to cut steels mitering from -45° to +60°. In addition to the automatic cutting cycle, it can also operate in semi-automatic mode. The automatic vertical circular sawing machine with controlled head rotation, ideal for those having the need for high production and angle cutting
![TIGER 372 CNC LR 4.0 RC](https://www.sawing.co.id/wp-content/uploads/2024/03/TIGER-372-CNC-LR-4.0-RC.jpg)
Cast-Iron Structure
Cast-iron structure to absorb vibrations and ensure greater cutting stability and longer blade ife.
![CAST-IRON STRUCTURE 6](https://www.sawing.co.id/wp-content/uploads/2024/03/CAST-IRON-STRUCTURE-6.jpg)
Industry 4.0 Ready -IOT
The optional IOT allows to maximize data collection and use them in favor of a better sawing machine cutting performance and longer blade life.
![INDUSTRY 4.0 READY -IOT](https://www.sawing.co.id/wp-content/uploads/2024/03/INDUSTRY-4.0-READY-IOT-3.jpg)
Motion of The Saw Head on Linear Guides
Motion of the saw head on linear guides with preloaded ball screw slides that ensures a mechanical vibration reduction during the cut.
![MOTION OF THE SAW HEAD ON LINEAR GUIDES 1](https://www.sawing.co.id/wp-content/uploads/2024/03/MOTION-OF-THE-SAW-HEAD-ON-LINEAR-GUIDES-1.jpg)
Adaptive Saw Head Down Feed Rate
Self-regulation in real-time of head down feed rate according to the type of material that grants a great surface finishing in any working condition, even in case of blade wear.
![ADAPTIVE SAW HEAD DOWN FEED RATE](https://www.sawing.co.id/wp-content/uploads/2024/03/ADAPTIVE-SAW-HEAD-DOWN-FEED-RATE-5.jpg)
Technical Data Semi Automatic Circular Saw Machine TIGER 372 CNC LR 4.0 RC MEP
Cutting range – dimensions obtained with optimized use of the supplied jaw set
Ø | ![]() | ![]() | ![]() | ![]() | |
0° | 370 | 110 mm | 95 mm | 180 x 95 mm | |
+ 45° | 370 | 80 mm | 80 mm | 80 x 95 mm | |
+ 60° | 370 | 30 mm | 30 mm | 30 x 85 mm | |
– 45° | 370 | 55 mm | 55 mm | 55 x 80 mm |
Cutting range – with pair of long movable jaws
Ø | ![]() | ![]() | ![]() | ![]() | |
0° | 370 | 110 mm | 95 mm | 180 x 95 mm | 70 x 100 mm |
+ 45° | 370 | 60 mm | 65 mm | 60 x 95 mm | |
+ 60° | 370 | 25 mm | 25 mm | 25 x 85 mm | |
– 45° | 370 | 35 mm | 35 mm | 35 x 80 mm |
Cutting range – with pair of medium movable jaws
Ø | ![]() | ![]() | ![]() | ![]() | |
0° | 370 | 110 mm | 95 mm | 180 x 95 mm | 70 x 100 mm |
+ 45° | 370 | 65 mm | 65 mm | 65 x 95 mm | |
+ 60° | 370 | 25 mm | 25 mm | 25 x 85 mm | |
– 45° | 370 | 40 mm | 40 mm | 40 x 80 mm |
Cutting range – with pair of short movable jaws
Ø | ![]() | ![]() | ![]() | ![]() | |
0° | 370 | 110 mm | 95 mm | 180 x 95 mm | 70 x 100 mm |
+ 45° | 370 | 75 mm | 75 mm | 75 x 95 mm | |
+ 60° | 370 | 30 mm | 30 mm | 30 x 85 mm | |
– 45° | 370 | 50 mm | 50 mm | 50 x 80 mm |
PERFORMANCE CHARACTERISTICS
Max. vice opening | 190 mm |
Rest piece no longer feeded | 260 mm |
Circular blade size | HSS 370 x 32 x 3 mm |
Blade motor power | 5.5 Kw – Three-phase |
Blade rotation speed | 15 ÷ 150 rpm |
